ISO9001 3 Axis 10X Aerial Inspection Drone Dual Beam Camera

Basic Information
Place of Origin: China
Brand Name: NLD
Certification: ISO9001 CE FCC
Model Number: NIA-Z10TIR
Minimum Order Quantity: 1set
Price: Negotible
Packaging Details: Aluminum Box
Delivery Time: 20days
Payment Terms: L/C, T/T, D/P, D/A
Supply Ability: 100sets/month
Name: Industrial Grade Drone Use: Industrial Inspection
Camera: Dual Beam Camera Visible Light Camera: 10 Optical Zoom 1920*1080
Thermal Imager: 640*480 Drone: 4 Rotors
High Light:

10X Aerial Inspection Drone


ISO9001 3 Axis Aerial Inspection Drone


ISO9001 aerial filming drone

Industrial Grade Drone 10x Optical Zoom Dual Beam Tracking Camera 1/3" Panasonic CMOS with Thermal Imager for Inspection

ISO9001 3 Axis 10X Aerial Inspection Drone Dual Beam Camera 0

Professional 3-axis High-precise FOC Program

Stabilizing the Z10TIR is a highly optimized 3-axis camera gimbal with pinpoint-precise motor rotation with a control accuracy of ±0.02° powered by a dedicated processor. Rather than rely on electrical slip rings - as is common with many gimbals - the Z10TIR uses a unique mechanically limited design and concealed wires to ensure more stable data transmission and greater durability. Vibration is eliminated using four damping balls and a lightweight damping board, creating seamlessly smooth video. 360°rotation remains possible through gimbal rotation. Stable, smooth footage image can be captured even when flying at high speed flight.


10x Zoom Camera

Powered by 1/3" CMOS module, with color 0.5lux@F1.6. 2.48mega effective pixel and 1080p FHD image quality, combined with powerful optical zoom technology, fast auto-focus speed,designed for UAV aerial photography.


Powerful 25mm Thermal Imager

Integrated French ULIX high-precision uncooled long wave (8μm ~14μm ) with 25mm lens thermal image sensor, Z10TIR can record and transmit thermal image and visible images at the same time. There are two different thermal resolutions for optional: 640*480 as standard version and 384*288 resolution as low configuration. See the unseen. ULIX thermal sensors reveal details invisible to the naked eye by making subtle differences in temperature visible. This new view on the world can reveal when equipment or buildings are damaged, the location of lost people and much more.

ISO9001 3 Axis 10X Aerial Inspection Drone Dual Beam Camera 1

Visible Light and Thermal Imager Dual Sensors Object Tracking

Build-in normalization, cross-correlation and tracking algorithm, combining with object missing recapture algorithm, achieve stable track of the target. Support custom characters of user OSD, adaptive gate, cross cursor, trace information display. The tracking speed is up to 32pixel/frame,object size range is from 16*16 pixel to 160*160 pixel, with the minimal signal-to-noise ratio (SNR) 4dB, the mean square root values of pulse noise in the object position < 0.5 pixel, which greatly improve the accuracy and tracking effect.



Drone Frame 4-rotor drone frame 1
Flight control PX4 1
Remote controller

Highlight tablet with Android system / Industrial-grade radio anti-interference ability

Remote data transmission and image transmission three in one

1080P HD image transmission / Support Ethernet/HDMI video input

Li-battery Super Lip Battery 12000mah 1
Propeller 2sets each set 4pcs 8
Charger Smart charger 1
Tools   1
Aluminum box   1



NIA-Z10TIR quad rotor industry drone is suitable for smart cities, police safety, road traffic, environmental protection and water conservancy, power line inspection, emergency rescue, oil pipeline inspection, surveying and other fields.
Aircraft size 460x460x250mm Long battery life Max 60min
Weight 2.4kgs Payload 1.5kgs
Max takeoff weight 4kgs FPV camera 1080P
Work temperature -10~50℃ Max wind speed 15m/s
