8KG T10 FCC Powerline Inspection Drone , Aerial Camera Drone

Basic Information
Place of Origin: China
Brand Name: NLD
Certification: ISO9001 CE FCC
Model Number: NPA-805H-8
Minimum Order Quantity: 1set
Price: Negotible
Packaging Details: Aluminum Box
Delivery Time: 20days
Payment Terms: L/C, T/T, D/P, D/A
Supply Ability: 100sets/month
Flight Time: 25~30minutes Payload: Max 8kgs
Using: Transmission Line Flight Control: DJI NAZA V2
Material: Carbon Fiber & Aluminum Battery: 16000mAh Lithium Battery
High Light:

FCC powerline inspection drone


ISO9001 T10 powerline inspection drone


8KG aerial camera drone

UAV for Power Line Long Flight Time Heavy Load Works for Transmission Line Stringing Pilot Rope  with Take-up Reel

8KG T10 FCC Powerline Inspection Drone , Aerial Camera Drone 0


Item number NPA-805H
Rotor 8pcs Propeller 8pcs
Motor 8pcs brushless Aircraft arm 8pcs foldable
Gimbal Single axis Camera 720P camera
Fail-Safe With GPS With
Motor axle distance 1080mm Total height 450mm
Payload Max 8kg No-load flight time 25-30min
Take-off weight Max 14kg Load flying time 12-18min
Flying speed 0~15m/min Flight mode Manual; ATT; GPS
Drone empty weight 4kg Battery Tattu 16000mAh 6S
Max flight distance 2~4km Flight height from 0~1000m
Working Temperature -5℃~50℃ Diameter of pilot rope 2~4mm
Functions: GPS positioning, battery power backhaul, national exclusive high beam function, OSD flight data real-time backhaul, full-auto return, semi-auto return, low-voltage protection alarm, runaway protection, headless mode, heading lock, etc.
1 Drone with DJI FC 1 set
2 200W Dual Channel Battery Charger 1 set
3 T10 Remote controller with Charger 1 set
4 Tattu 16000mAh lithium battery 2 pcs
5 Battery for remote controller 1 pcs
6 Battery voltage checker 1 set
7 Drone Tools 1 set
8 Aviation aluminum case box 1 pcs
9 Spare screws 1 pack
10 Backup battery strap 4 pcs
11 Spare propeller 8 pcs
12 6.5" Mobile phone 1 set


Remote control

Remote Controller details
Model T10 Channel 10 channels
Voltage 4.2V Current 100mA
Frequency 2.400~2.483GHz Modulation New FHSS
Dimension 160x150x50mm Battery 4000mAh
Duration 10h Charge Port Micro-USB
Receiver details
Model RIO Size 50x31x12mm
Current 100mA Weight 20g
Voltage 4.5~5.5V Channels 10 channels


Digital Camera

Resolution 720P
Working method Video, Photo
Support memory card type Micro SD card (Max 128G)
Working voltage 5Voltage
Working current 180mA
Camera Weight 67g
Camera Size 71x51x48mm
Interface Type Network interface
Control display mode Windows system PC; Android phone, tablet
Working environment temp. -10℃ ~ 50℃
Camera Gimbal Single axis gimbal
Controllable rotation range Pitch: +10°~90°


Please pay more attention. Misuse of this product may result in injury, damage or loss of property. Please read the manual carefully before using our product. This item is not a toy. This item is intended for use by professional UAV operators and installers only. Don't use this product if you lack the knowledge and expertise to install and maintain UAV radio equipment. Don't use unapproved or unofcial components with this system. Operators must strictly follow the operation guides set forth in this manual. We does not accept any liability for the use or misuse of the drone.


More photos

8KG T10 FCC Powerline Inspection Drone , Aerial Camera Drone 1

8KG T10 FCC Powerline Inspection Drone , Aerial Camera Drone 2

8KG T10 FCC Powerline Inspection Drone , Aerial Camera Drone 3

Take-up Reel
