GPS 5000m FCC Aerial Photography Drones Low Battery RTH Lose Control RTH One Key RTH

Basic Information
Place of Origin: China
Brand Name: NLD
Certification: ISO9001 CE FCC
Model Number: NTA-CFLY-18
Minimum Order Quantity: 1set
Price: Negotible
Packaging Details: Oxford bag
Delivery Time: 20days
Payment Terms: L/C, T/T, D/P, D/A
Supply Ability: 100sets/month
Name: Remote Control Camera Drone Remote Controller: 1set
Frequency: 5.8GHz 2.4GHz Maximum Signal Effective Distance: 5km
Voltage: 3.7V Current: 500mA
High Light:

5000m aerial photography drones


GPS aerial photography drones


FCC aerial survey drone

Camera Drone with Six Flight Modes, GPS, Altitude, Return to Home, One-Key RTH, Low Battery RTH, Lose Control RTH
GPS 5000m FCC Aerial Photography Drones Low Battery RTH Lose Control RTH One Key RTH 0
Flight Modes
GPS mode:
When the aircraft is on GPS mode, it can achieve accurate hover of the aircraft. When the GPS signal is weak, the aircraft will automatically enter altitude mode or vision poptical flow positing mode.
Altitude Mode:
In Altitude Mode, when the optical flow positioning conditions are satisfied, the aircraft will automatically enter the optical flow positioning mode, in the optical flow positioning mode, the aircraft can hover stably with the optical flow positioning system.
Return To Home (RTH)
Aircraft has Return-to-home (RTH) function, and there are 3 types of RTH: one-key RTH, low battery RTH and lose control RTH.
GPS 5000m FCC Aerial Photography Drones Low Battery RTH Lose Control RTH One Key RTH 1
One-key RTH
The aircraft can return to the return point via the"RTH" button on the remote control
Low Battery RTH
During the flight, when the red light of the aircraft status indicator flashes slowly, the aircraft triggers low battery RTH.
Lose Control RTH
If the remote control signal continues to be lost for more than 2 seconds, the flight control system will take over the control of the aircraft and control the aircraft to fly back to the last recorded return point.
1. Aircraft

Max Ascent Speed

Clam mode: 2m/s
Normal mode: 2m/s
Sport mode: 5m/s

Max Descent Speed

Clam mode: 1.5m/s
Normal mode: 1.5m/s
Sport mode: 2m/s

Max Speed

Clam mode: 5m/s
Normal mode: 10m/s
Sport mode: 19m/s

Max Service Ceiling Above Sea5000m
Max Fight Time35mins
Satellite Positioning SystemsGPS/GLONASS
Hover Accuracy Range

Vertical: +/-0.5m±0.2m(ultrasonic system, optical flow system works)
Horizonal: +/-1.5m±0.3m(ultrasonic system, optical flow system works)

Maximum Flight Height120m(Maximum 500m(Need to change setting on app))
Operating Temperature Range0℃-40℃

2. Optical flow system

Operating EnvironmentSurface with clear pattern and adequate lighting(lux>15)
Velocity Range≤1.5m/s at 6.6 ft (2m) above ground
Altitude Range0.2-4.5m

3. Ultrasonic altitude system

OperatingExcept for surface of water or ground of absorbing material(such as thick carpet)
Velocity Range≤3m/s
Altitude Range0.2-4.5m

4. 3-axis Gimbal

ControllablePitch: -90°-0°

Pitch: +30/-120°
Roll: ±35°
Yaw: ±30°

5. Camera

SensorAmbarella A12, SONY CMOS
Image Size5120*3840(20MP)
Shooting modeSingle shot
Video Recording Resolution3840*2160
Maximum Video Bit60Mbps
Supported File SystemsFAT32(<=32GB)/exFAT(>32GB)
Supported SD CardsMicro SDTM Max capacity: 128GB, UHS-I Speed Grade 3 rating required
Operating Temperature Range0℃-40℃

6. Battery

Battery TypeLiPo 3S
Net Weight196g
Max charging power35W
Charge time<5h(with 5V 2A adapter)
Charging Temperature Range0℃-40℃

7. APP

Mobile APPC-Fly 2
Live View Quality720P
Aerial Photography modedronie, rocket, circle, helix
Required Operating SystemsAndrio 5.0 above, ISO 9.0 above
FPV Transmission Distance5000m

8. Charger

Input5V 2A(recommend)
Output4.35V 0.7A*3
Rated Power10W

9. Remote Controller

Operating Frequency5.8GHz
Max Transmission Distance5000m
Transmitter Power(EIRP)

FCC: ≤23dBm
CE: ≤14dBm
SRRC: ≤20dBm

Operating Current/Voltage500mA@3.7V
Battery Capacity(built-in)3.7V
Battery TypeLiPo 18650 1S
Battery Power9.62Wh
Operating Temperature Range0℃-40℃
Supported Mobile Device SizeThickness Supported: 6.5-8.5mm
Maximum Charge Power5W
Charge Time<3h(with 5V 2A adapter)

GPS 5000m FCC Aerial Photography Drones Low Battery RTH Lose Control RTH One Key RTH 2
GPS 5000m FCC Aerial Photography Drones Low Battery RTH Lose Control RTH One Key RTH 3
