NPA610 Industrial Aerial Drones GPS For Power Line Construction

Basic Information
Place of Origin: China
Brand Name: NLD
Certification: ISO9001
Model Number: NPA610
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Box
Delivery Time: 15~25 days
Payment Terms: L/C, T/T, D/P, D/A
Supply Ability: 100sets/month.
Type: Industrial Grade Drone Payload: 0~5kg
Image Transmission Distance: 10~15km Horizontal Speed: 0~15m/s
Working Time: 30~50min Motor Wheelbase: 1200mm
High Light:

NPA610 GPS industrial aerial drones


Power Line Construction industrial aerial drones

NPA610 Industrial Grade Drone With Gps For Power Line Construction

Motor wheelbase


Working time


Max takeoff weight




HD Camera


Image transmission distance


Horizontal speed


Wind resistance


NPA-610 for power line, Flight control 3 redundant accelerometers and gyroscopes.
It can work for full construction section, long time flying suitable for smart cities, road traffic, environmental protection, police safety and water conservancy, power line inspection, surveying and other fields, emergency rescue, oil pipeline inspection.

NPA610 Industrial Aerial Drones GPS For Power Line Construction 0
Suspension components

10x optical zoom +Thermal imaging dual-optical three-axis gimbal

Voltage3S / 6S(DC12V-26V)
powerDynamic 12W

Work characteristics

Roll angle action range-45°~ +135°
Pitch angle action range-120°~+120°
Course angle action range-150°~+150°
The amount of pitch and roll angle jitter±0.02°
The amount of horizontal angle jitter±0.03°
One-key back to centering functionOne-key automatic and quick return to the initial position

pan-tilt control speed is adjustable

Support angle and speed control
When the gimbal rotates, the speed is adaptive based on the current speed mode and the multiple of the visible light camera.

Store TF cardSupport 16G to 128G class10 TF card
Control modeSupport UART control and SBUS control
FeaturesHDMI picture-in-picture switching, pseudo-color switching, temperature measurement

White light camera parameters

CMOS size1/3 inch 4 million pixel CMOS SENSOR
Optical zoom10x HD optical zoom lens, f=4.9 to 49mm
Focus timeReal-time fast focusing function, focusing time <1S
Video outputHDMI 1080P 60FPS, video stream local TF storage

Field of View (FOV)

D : WIDE 66.6º±5% TELE 7.2º±5%
H : WIDE 53.2º±5% TELE 5.3º±5%
V : WIDE 39.8º±5% TELE 4.2º±5%

Support mode1080P 60fps

Thermal Imaging

Resolution320*240 pixel
Pixel spacing12μm
TypeUncooled focal plane microbolometer
Wavelength range8~14μm
Thermal sensitivity (NETD)≤65mk@30℃
Contrast, brightnessAdjustable
Field of view6.5mm Lens, angle:34.4 x 25.8
Measurement function

Center point, the highest temperature and
the lowest temperature display temperature function;

Overall size108mm*150mm*180mm
Working environment-10℃ to +45℃ / 20% to 80% RH
Storage environment-20℃ to +60℃ / 20% to 95% RH
Main applicationDrone aerial photography
Weight610±20 g
