2.4G ISM 4km UAV Parts , 5V 2A PIX APM Drone Remote Control

Basic Information
Place of Origin: China
Brand Name: NLD
Certification: ISO9001 FCC
Model Number: NLVD32-1
Minimum Order Quantity: 1set
Price: Negotible
Packaging Details: Carton
Delivery Time: 20days
Supply Ability: 100sets/month
Work Range: Max 4km Operate Display: 2.8" LCD Screen
Wireless Type: 2.4G ISM / Bluetooth Charger: 5V 2A
Date Storage: SD Card Mdel Date Memory: 64 Sets
High Light:

4km UAV Parts


2.4G ISM UAV Parts


ISO9001 2.4G APM Drone Remote Control

Remote Control Data & Image Transmission Remote Controller for Industrial Grade Drone Max Work Range 4000m


Quick details:

Applicable model: Planes / Helicopters / Gliders / Quadcopters / Multi-rotors / Vehicles / Boats / Robots

Compatible FC: Oper source flight controllers PIX/APM etc.

Language display: Chinese / English

Joystick Resolution: 4096 grades

Frequency Band: 2.400 Mhz ~ 2.483 Mhz



Advanced spread-spectrum technology

VD32 transmitting system is applied with our technology’s lately upgraded bidirectional 2.4GHz spread-spectrum technology. The maximum control range can be 4km (unobstructed, free of interference). VD30 transmitter and its receiver are linked by a unique matching code, and the enhanced anti-interference ability supports multiple transmitters working in stability synchronously.

Extraordinary handling & Accurate Manipulating Experience

VD32 transmitter fits user’s palm perfectly, fashionably streamlined and compact industrial design.

16-Channel Fast-response mode

VD32 transmitter is equipped with various types of buttons, dials, and switches. 16 channels support all kinds of models, including fixed-wings, helicopters, gliders, quadcopters, and multi-rotors, and major farming drones on market.

Built-in High Capacity Li-Po Battery, 9H Super Long Working time

VD32 transmitter comes with an 8000mAh Li-Po 1S built-in rechargeable battery, reliable and easy to maintain. You can charge the transmitter through Micro-USB port, and it can work continuously for 9 hours after a full charging. You’ll never have to worry about long-time business flight in outdoors.

4-Kilometer Control Range

VD32's control range can reach 4 kilometers, which covers the business flight range for most agricultural drone pilots. A perfect mate for BVR (Beyond Visual Range) flights.

In the built-in screen of VD32 transmitter, it displays real-time telemetry of the sky unit voltage, aircraft power, transmission signal strength, information of the GPS module and other multi-sensors.

Voice Broadcast with Vibration Alert

The voice broadcast function with vibration alert help users be more concentrating on flight.

High Brightness Colorful LCD Touch Screen, Brand New GUI System VD32 transmitter’s high brightness colorful screen is clearly visible under direct sunlight. Few complicated keys and buttons, but a built-in LCD touchscreen, with a turntable menu and a brand-new GUI system. These revolutionary new features made by both software and hardware provide a more user-friendly experience.

Creative 5-dimensional Sub-trim Buttons

The Sub-trim button design on traditional transmitters have been overturned on VD32, now you are able to do quick adjustment between sub-trim buttons and joysticks in a flight. The sub-trim buttons are made of elegant aluminum alloy, CNC Molding, along with a unity industrial design, extraordinary manipulating experience.

2.4G ISM 4km UAV Parts , 5V 2A PIX APM Drone Remote Control 0

Ground side
Battery Type & Power

Li-Po 1S battery 3.7V 8000mAh Chargeable

Charging Time 5 Hours
Battery Life 8 Hours
Charging Port Type Micro-USB; 5V/2A
Dimensions 184.5X180X114 mm
Net Weight 780 g
Sky side
Signal Output 14 channels of SBUS, 5 channels of PWM
Datalink Ports (to FC) UART, CAN (optional)
Dimensions 59 x 59 x 16 mm
Net Weight 50g
Language Display Chinese / English
Joystick Resolution 4096 grades
Receiving Sensibility -101 dBm
Model Data Memory 64 sets(extensible)
Channels 16 Channels
Frequency Band 2.400 MHz - 2.483 MHz
Screen Type 2.8-Inch High Brightness Colorful LCD Screen 240x320
Control Range 4 km
Charging Port Micro-USB Port

Wireless Type &


2.4G ISM
Charging Port Micro-USB Port
Packing Size 245X190X170 mm
Packing Weight 1350 g

2.4G ISM 4km UAV Parts , 5V 2A PIX APM Drone Remote Control 1

2.4G ISM 4km UAV Parts , 5V 2A PIX APM Drone Remote Control 2
