NPA-610 Drones In Construction Industry For 3D Sand Table Modeling Of Emergency Disaster

Basic Information
Place of Origin: China
Brand Name: BOYU
Certification: ISO9001 CE FCC
Model Number: NPA-610
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Box
Delivery Time: 15~25 days
Payment Terms: L/C, T/T, D/P, D/A
Supply Ability: 100sets/month.
Type: Industrial Grade Drone HD Camera: 1080P
Motor Wheelbase: 1200mm Payload: 0~5kg
Image Transmission Distance: 10~15km Wind Resistance: 6
High Light:

NPA-610 drones in construction industry


1080P Camera industrial drone inspection


Road patrol uav industrial inspection

NPA-610 Industrial Grade Drone For 3D Sand Table Modeling of Emergency Disaster


NPA-610 Industrial Grade Drone

 Max takeoff weight


 HD Camera


 Wind resistance


 Horizontal speed


 Motor wheelbase


 Image transmission distance




 Working time



Aerial emergency surveillance patrol

Power inspection

Road patrol

3D Sand Table Modeling of Emergency Disaster

Emergency communication network relay

River conservancy inspection


Suspension components


4K HD optical zoom gimbal

Lightweight Gimbal weight 286g

One-key to center:

  • Double-click the target, center zoom function

Available SDK:

  • Sky data interface and ground station SDK is available

High resolution, zoom:

  • 12 million pixels, up to 4K recording
  • 14 times zoom (3.5 times optical * 4 times digital)

Object Tracking

High stability Jitter Angle: ±0.01°

GPS information record:

  • Superimpose GPS information display and save to subtitle file


General Parameter
  Product   NGC-C4K: 4K HD optical zoom gimbal
  Working voltage   12V-25V
  Power   6W
  Weight   275g
  Size   96*79*120mm
  Interface Type   Network interface
  Control display mode   Windows system PC; Android phone, tablet


Environment parameter
  Working environment temp.   -10℃ ~ 60℃
  Storage environment temp.   -20℃ ~70℃


Camera parameter
  • CMOS: 1/2.3″;
  • 12.71 million total pixels;
  • maximum resolution 4152*3062
  • 3.5x optical zoom lens F 3.85~13.4mm
  • Minimum shooting distance: 1mm~3mm (near focus ~ far focus)
  • Field of view (horizontal): 82~25°
  Image storage format   JPEG
  Video storage format   MP4
  Working method   Video, photo


Gimbal parameter
  Jitter Angle   ±0.01°
  Installation method   Detachable
  Controllable rotation range   Pitch/Tilt: +70°- -110°; Yaw/Pan: ±300°
  Structure design scope Roll   Pitch/Tilt: +75º- -100º; Yaw/Pan: ±310°; roll: +90°- -50°
  Maximum control speed   Pitch/Tilt: 120°/s; Yaw/Pan: 180°/s
