Name: FCC CE Power Line Drone For Survey Remote Control Drone Powerline Inspection
Brand: NLD
SKU: NPA-805H
Price: 1.00 USD
Availability: InStock
Rating: 4.9 (117 reviews)

NPA-805H Remote Control Powerline Drone With FCC CE Certificate

Product parameters

Model: NPA-805H
Axle distance: 1080mm
Height: 450mm
Camera: Single Axis Gimbal 720P
Fail-Safe: with
GPS: with
Maximum tension: 8kg
No-load endurance: 25-30min
Maximum take-off weight: 14kg
Load endurance: 12-18min
Flying speed: 0~15m/min
Flight mode: Manual control; ATT; GPS
Empty weight: 4kg
Battery: 16000mAh 6S
Maximum flight distance: 2-4km
Flight height: 0-1000m (adjustable)
Working Temperature: -5℃-50℃
Diameter of traction rope: 2-4mm

Functions

GPS positioning
full-auto return
semi-auto return
runaway protection
headless mode
heading lock
low-voltage protection alarm
battery power backhaul
national exclusive high beam function
OSD flight data real-time backhaul

Characteristic

Low terrain requirements, unlimited altitude, and no problems in high altitude areas;
Environment friendly, in line with the national requirements for energy conservation and environmental protection;
It is more efficient to drag a 3.5mm, 12 kg rope to 1000 meters. (four axis resistance 2.0mm);
High efficiency, high attendance, short takeoff adjustment time
It is safer and can resist force six winds;
Convenient maintenance and low maintenance cost;
The aircraft is light and flexible with small vibration;
2.0 DuPont rope payload, which can fly for 25-30 minutes;
Free operation training. Welcome to our company to learn the maintenance technology service of simple UAV.

FCC CE Power Line Drone For Survey Remote Control Drone Powerline Inspection 0

Application

In the traditional setting out operation on the Yangtze River, the towline can only be towed by tugboats on the water surface. The construction water surface must be sealed first. The closure of navigation will also cause many economic losses to the country and the construction party. The staff stood on the ship and dragged the helicopter with the guide rope remotely, so that the guide rope could fly over the Yangtze River and avoid sealing.

In the process of circuit reconstruction, there is usually cross power charging. It is necessary to cross a new line on the basis of the energized line. In order to ensure the safety of construction workers, traditional buildings can only be used first. After the line is powered off and then built, aerial drones can be used to avoid power failure.

During the construction of the State Grid, trees in the primeval forest often encounter shrubs, primeval forests, etc. This will definitely affect the construction progress. Trees cannot be cut down when crossing the primeval forest. This undoubtedly adds a lot of difficulties to the construction of the project, and with the lined UAV, it is easy to fly over trees and throw the guiding rope to the ground.

Swamps, lakes, farmland, roads, mountains, etc. will also be encountered during construction. When people cannot realize the construction of the line, the drones on the line will also display their talents and complete the task.

Tag:

Place of Origin:	China
Brand Name:	NLD
Certification:	ISO9001 CE FCC
Model Number:	NPA-805H

Minimum Order Quantity:	1set
Price:	Negotiable
Packaging Details:	Box
Delivery Time:	15~25 days
Payment Terms:	L/C, T/T, D/P, D/A
Supply Ability:	100sets/month.
